SP1 Static pressure probe

Catégories: Poultry, Swine, Probes, Dairy, Probes, Probes, Probes, Horticultural, Static Pressure, Static Pressure, Static Pressure, Static Pressure

Knowing all the variables which influence agricultural production, real-time data collection is not an option, but an obligation! Monitrol offers a wide range of probes and sensors to keep you up to date of the changing parameters affecting your production. Humidity probes, static pressure sensors, temperature probes, ammonia sensors, each measurement system sold by Monitrol offers precise readings while being specifically designed for the agricultural sector. Most are equipped with MGCB connectors.

The GE-SP1 static pressure probe is a precise measuring tool that converts static pressure into a standard 4-20 mA signal.

It is used to measure the pressure difference between 2 rooms or between a building’s interior and the exterior.

Thanks to its magnetic sensor, the GE-SP1 supplies an exceptional long-term performance.

This probe is the ideal solution for all applications requiring static pressure and air flux readings.

Static pressure probe


Technical specifications


Notable features of the GE-SP1 include:

  • Easy installation
  • Reliable readings
  • Rugged, durable fabrication
  • Available with or without voltage adapter
  • Your data accessible on FarmQuest via your compatible GENIUS control


  • Weight 8 oz (230 g)
  • Tubes 3/16’’ (5 mm) internal ; 0.45’’ (9 mm) external
  • Temperature limits 0 °F to 150 °F (-18 °C to 66 °C)
  • Pressure limits 1 psi maximum, operation; 10 psi, burst
  • Relative humidity 90% maximum without condensation
  • Power requirements 12 VDC
  • Output signal 4 to 20 mA, 2 wires
  • Current consumption 40 mA max
  • 240 V
